G10
TECHNICAL SPECIFICATION
| Item Specification | |
| Single Beam Models | H1 H3 H7 H8 H9 H10 H11 H15 H16 9005 9006 9012 P13W/PSX26 5202/PSX24 |
| Hi Lo Beam Models | H4HILO H13HILO 9004HILO 9007HILO |
| LED Chip Type | 2 * 9W(Single beam);4*9W(Hi Lo Beam) H15 30W+DRL 10W |
| Voltage | DC 8-32V (V-start: 6V) (H13,9004,9007,H15 9-32V) |
| Current | 1.299A-DC13.5V, |
| Operating Power | 17.5365W |
| Lumen | 3600LM |
| Color Temp | 5700K |
| Working Temp | -45°C~+85 °C |
| Chip working temp | -40°C~+120 °C |
| Protection Function | Reverse polarity protection |
| Life Span | >10000 hours |
| Remarks | Anti-EMI(anti-electromagnetic interference): S95/54/EC |
PRODUCT DISPLAY
PRODUCT DESCRIPTION
Same size of luminous focus as standard halogen bulbs
Standard light beam pattern, type of anti-glare
Standard light cutting line and high brightness
Perfect light beam pattern, no glare;
Form effective lighting upgrade 200%
Plug and play, non-destructive & fast installation
Small body, it can fit all cars
CANBUS no error for 99% of new cars
It can use in 12V and 24V
Long life and less defetive rate
360 degree adjust
Practical and patented technology
